[C#] How to Set Paragraph Alignment (Left, Center, Right) in Word Documents with OpenXML SDK

Overview

When creating Word documents using the OpenXML SDK, you can programmatically control the alignment of each paragraph (Left, Center, Right, Justified/Both). This is achieved by adding the Justification information inside the ParagraphProperties of a paragraph to adjust the text position.

Specifications (Input/Output)

• Input: File path, text string, and alignment type (JustificationValues).
• Output: A .docx file with the specified alignment settings applied.
• Library: DocumentFormat.OpenXml (NuGet package).

Implemented Methods

Basic Usage

using DocumentFormat.OpenXml.Wordprocessing;

using var generator = new SimpleWordGenerator("AlignmentTest.docx");

// Left alignment (default)
generator.AppendParagraph("This text is left-aligned.");

// Center alignment
generator.AppendParagraph("Centered Title", JustificationValues.Center);

// Right alignment
generator.AppendParagraph("January 1, 2025 Right-aligned", JustificationValues.Right);

Full Code Example

using System;
using DocumentFormat.OpenXml;
using DocumentFormat.OpenXml.Packaging;
using DocumentFormat.OpenXml.Wordprocessing;

class Program
{
    static void Main()
    {
        string filePath = "AlignmentExample.docx";

        try
        {
            Console.WriteLine($"Generating {filePath} ...");

            using (var doc = new SimpleWordGenerator(filePath))
            {
                // 1. Left alignment (Left)
                doc.AppendParagraph("This is a left-aligned paragraph.", JustificationValues.Left);

                // 2. Center alignment (Center)
                doc.AppendParagraph("This is a centered paragraph.", JustificationValues.Center);

                // 3. Right alignment (Right)
                doc.AppendParagraph("This is a right-aligned paragraph.", JustificationValues.Right);

                // 4. Justified (Both) - effective for long blocks of text
                string longText = "Justified alignment (Both) automatically adjusts character spacing " +
                                  "so that both the left and right edges of the lines are clean. " +
                                  "It is frequently used in formal documents and reports to improve visual presentation.";
                doc.AppendParagraph(longText, JustificationValues.Both);
            }

            Console.WriteLine("Done.");
        }
        catch (Exception ex)
        {
            Console.WriteLine($"Error: {ex.Message}");
        }
    }
}

/// <summary>
/// Word document generation class supporting paragraph alignment.
/// </summary>
public sealed class SimpleWordGenerator : IDisposable
{
    private WordprocessingDocument _document;
    private Body _body;

    public SimpleWordGenerator(string filePath)
    {
        // Initialize document and Body
        _document = WordprocessingDocument.Create(filePath, WordprocessingDocumentType.Document);
        MainDocumentPart mainPart = _document.AddMainDocumentPart();
        mainPart.Document = new Document();
        _body = mainPart.Document.AppendChild(new Body());
    }

    public void Dispose()
    {
        _document?.Dispose();
    }

    /// <summary>
    /// Adds a paragraph with the specified alignment.
    /// </summary>
    /// <param name="text">Text to write</param>
    /// <param name="align">Alignment (Left, Center, Right, Both, etc.)</param>
    public void AppendParagraph(string text, JustificationValues align = JustificationValues.Left)
    {
        // 1. Generate Paragraph
        var paragraph = new Paragraph();

        // 2. Generate ParagraphProperties (pPr)
        var pPr = new ParagraphProperties();

        // 3. Generate Justification and add to properties
        // Set the JustificationValues enum to the Val property
        var justification = new Justification() { Val = align };
        pPr.Append(justification);

        // 4. Apply properties to the paragraph
        paragraph.Append(pPr);

        // 5. Generate and add text portion (Run > Text)
        var run = new Run();
        run.Append(new Text(text));
        paragraph.Append(run);

        // 6. Add to Body
        _body.Append(paragraph);
    }
}

Customization Points

• Changing Default Values: In some document standards, “Justified (JustificationValues.Both)” is preferred. It is convenient to change the method’s default argument to Both.
• Adding Indentation: You can also set indentation by adding an Indentation object to ParagraphProperties.Example: Adding a left indentpPr.Append(new Indentation() { Left = “720” }); // Approx. 1.27cm (1440 = 1 inch)

Important Notes

• Property Order: While the order of elements within a Paragraph is somewhat flexible in OpenXML, generally ParagraphProperties (pPr) must be added to the Paragraph before the Run.
• Effect of “Both”: JustificationValues.Both (Justified) will look the same as Left if the text is short enough to fit on one line. The effect only becomes visible when the text is long enough to wrap across multiple lines.
• Distribute: Using JustificationValues.Distribute will space characters to fill the entire width of the line regardless of character count. Use this carefully for headings, as it can result in extremely wide character spacing.

Advanced Usage

Centering Styled Headings

This example demonstrates how to apply a heading style while simultaneously centering it.

public void AddCenteredHeading(string text)
{
    var p = new Paragraph();
    var pPr = new ParagraphProperties();

    // Specify Style ID "Heading1"
    pPr.Append(new ParagraphStyleId() { Val = "Heading1" });

    // Specify Center alignment
    pPr.Append(new Justification() { Val = JustificationValues.Center });

    p.Append(pPr);
    p.Append(new Run(new Text(text)));
    _body.Append(p);
}

Summary

To control the appearance of paragraphs in OpenXML, it is essential to understand the structure: placing ParagraphProperties directly under Paragraph, and then adding specific setting elements like Justification inside it. Once you master this pattern, you can set line spacing, background colors, and borders using similar procedures.
