[C#] How to POST Form Data (x-www-form-urlencoded) with HttpClient

Overview

This method allows you to send data in the application/x-www-form-urlencoded format, which is the same format used by standard HTML <form> tags. By using the FormUrlEncodedContent class, key-value pairs are automatically URL-encoded, and the appropriate Content-Type header is added to the POST request.

---

Specifications (Input/Output)

• Input: Data to be sent (a collection of key-value pairs).
• Output: Server response (response body).
• Prerequisite: Uses the standard .NET library (System.Net.Http).

---

Basic Usage

Pack your data into a Dictionary<string, string> and pass it to the constructor of FormUrlEncodedContent.

var formData = new Dictionary<string, string>
{
    ["username"] = "user01",
    ["message"] = "Hello C#"
};

// Automatic encoding (e.g., spaces become +) is performed
using var content = new FormUrlEncodedContent(formData);

// Execute POST
var response = await client.PostAsync("https://example.com/api/login", content);

---

Full Code Example

The following console application demonstrates sending “search settings” in form format and receiving the result.

using System;
using System.Collections.Generic;
using System.Net.Http;
using System.Threading.Tasks;

class Program
{
    // Reuse HttpClient to avoid socket exhaustion
    private static readonly HttpClient _httpClient = new HttpClient();

    static async Task Main()
    {
        // Target URL for testing
        string url = "https://httpbin.org/post";

        Console.WriteLine($"Destination: {url}");

        try
        {
            // 1. Prepare data to be sent
            // Define keys and values in a dictionary
            var parameters = new Dictionary<string, string>
            {
                ["keyword"] = "network",
                ["encode"] = "UTF-8",
                ["maxsize"] = "20",
                ["comment"] = "C# & .NET" // Symbols and spaces are automatically encoded
            };

            // 2. Create content (application/x-www-form-urlencoded)
            // Passing the dictionary to the constructor handles the conversion
            using var content = new FormUrlEncodedContent(parameters);

            Console.WriteLine("Sending POST data...");

            // 3. Execute POST request
            using var response = await _httpClient.PostAsync(url, content);

            // Verify status code (throws exception on failure)
            response.EnsureSuccessStatusCode();

            // 4. Display results
            string responseBody = await response.Content.ReadAsStringAsync();
            Console.WriteLine("\n--- Response from Server ---");
            Console.WriteLine(responseBody);
        }
        catch (HttpRequestException ex)
        {
            Console.WriteLine($"Communication Error: {ex.Message}");
        }
        catch (Exception ex)
        {
            Console.WriteLine($"Error: {ex.Message}");
        }
    }
}

---

Execution Result Example (Response from httpbin.org)

--- Response from Server ---
{
  "form": {
    "comment": "C# & .NET",
    "encode": "UTF-8",
    "keyword": "network",
    "maxsize": "20"
  },
  "headers": {
    "Content-Type": "application/x-www-form-urlencoded",
    ...
  },
  ...
}

---

Customization Points

• Collection Initializer: Using C# collection initializers makes the definition of key-value pairs concise.
• Sending Lists: To send multiple values for the same key (e.g., tag=csharp&tag=programming), use List<KeyValuePair<string, string>> instead of a Dictionary.

var multiValues = new List<KeyValuePair<string, string>>
{
    new("tag", "csharp"),
    new("tag", "programming")
};
using var content = new FormUrlEncodedContent(multiValues);

---

Important Notes

• Data Size: Because FormUrlEncodedContent converts all data into a single URL-encoded string, it is not suitable for binary data (like images) or extremely large text. Use MultipartFormDataContent for those scenarios.
• Character Encoding: Data is encoded in UTF-8 by default. If sending to legacy systems (e.g., Shift-JIS), you must manually create a ByteArrayContent with the pre-encoded byte array.

---

Advanced Application

Checking Encoded Content

You can verify the exact string being sent to the server for debugging purposes.

using var content = new FormUrlEncodedContent(parameters);

// Read as string for debugging
string encodedString = await content.ReadAsStringAsync();
Console.WriteLine(encodedString);
// Example output: keyword=network&encode=UTF-8&maxsize=20&comment=C%23+%26+.NET

---

Conclusion

FormUrlEncodedContent is the standard approach for simulating web form submissions or interacting with REST APIs that require application/x-www-form-urlencoded. By simply providing key-value pairs in a collection, you can delegate the complex URL encoding and Content-Type header management to the library, ensuring a safe and clean implementation.
